HD IP Dome Camera HT-S Series: S210, S213, S213-P, S220

HD IP Dome Camera HT-S Series: S210, S213, S213-P, S220

• H.264 Main Profile
• Support dual stream, AVI format
• Low power consuming of the DSP, suit to long time running
• The encoding parameter can be adjusted dynamically (bit rate/frame rate/image quality)
• Support 0.1M~6Mpbs bit rate adjustable; support 1~30fps adjustable
• Multi-mobile support(iPhone, Windows Mobile, BlackBerry, Symbian, and Android)
• Multi-browser support such as FireFox, Chrome, and Internet Exploerer
• Built-in Web server enables the use of a standard Web browser for viewing and management
• Support dynamic IP address, LAN, Internet (ADSL and Cable Modem)
• Support the whole TCP/IP protocols and RTSP/ FTP/ PPPOE/ DHCP/ DDNS/ NTP/ UPnP
• ONVIF Ver. 2.2 conformance
• Support CVBS video output and overlying DDNS, user name, password and other information
• Up to 10 viewers can directly access the camera simultaneously
• Optional POE


• S210: 1M
  Embedded RTOS design, dual core DSP(Hi3518E), pure hardware compression, watchdog
  Up to 25 frames per second in all resolutions ranging up to 720P(1280*720)


• S213: 1.3M; S213-P: 1.3M with POE
  Embedded RTOS design, dual core DSP(Hi3518C), pure hardware compression, watchdog
  Up to 25 frames per second in all resolutions ranging up to 960P(1280*960)


• S220: 2M
  Embedded RTOS design, dual core DSP(Hi3516C), pure hardware compression, watchdog
  Up to 25 frames per second in all resolutions ranging up to 1080P(1920*1080)



Note: Specifications are subject to change without prior notice.
